RM10

市 场 价:¥0

优 惠 价:¥0

库  存:999

选择商品:

商品详细

Model RM10
Engine & E-start Brand Diesel KOOP
(Euro V)
Gasoline LIFAN
(Euro V & EPA)
Gasoline KOHLER
(Euro V & EPA)
Displacement 499cc(11HP) 420cc(15HP) 429cc(14HP)
Output 7.6KW 10.5KW 10.4KW

Working ranges
Max. cutting height 2800mm
Max. loading height 1860mm
Max. digging depth 1600mm
Max. digging reach 1300mm
Max. digging radius 2900mm
Boom swing angle (left/right) 90°
Swing radius 1300mm
Undercarrige Track width 180mm
Track length 1230mm
Gradeability 30°
Dozer size Width 800mm
Lifting capacity(Height/Depth) 210mm/180mm
Dimensions Overall length 2200mm
Overall height 2250mm
Overall width 960mm
Hydraulic pump type 6ml/r
Swing motor type Cycloidal
Travel motor 315cc
Weight 930kg
40" HC Container 20pcs
