HT10T

市 场 价:¥0

优 惠 价:¥0

库  存:999

选择商品:

商品详细

Model

HT06T

HT10T

Capacity (max)

6000kg

10000kg

Max vehicle weight (with load and full equipment)

8200kg

13000kg

Trailer weight (the chassis)

1500kg

2050kg

Trailer weight with container

2200kg

3000kg

Hitch stress:

- trailer only

- trailer with empty container

- trailer with full load

575KN

787KN

2095KN

727KN

1151KN

2573KN

Trailer dimensions – the chassis:

Length

Width across wheels

Height: without container

4900mm

2000mm

1980mm

5600mm

2200mm

2180mm

Container dimensions

Length

width

height

weight

3600mm

1845mm

1260(700)mm

690kg

4300mm

2150mm

1450(700)mm

957kg

Tyres (forest)

400/60-15.5

400/60-15.5

Wheel quantity

2pcs

4pcs

Drive system

tractor

tractor

Wheel track

1520mm

1650mm

Brake

two

Four

Max speed

30-40km/h

30-40km/h

Tractor- power

60-80HP

80-100HP

Hydraulic pressure required

16-30MPa

16-30MPa

Hydraulic oil

6L

8L
