Model |
TTC03 |
TTC03A |
TTC03B |
|
|
Timber Crane |
||||
|
Max reach |
3.4m |
|||
|
Lifting capacity(3.4m) |
200kg |
|||
|
Turning radius of crane |
360° |
|||
|
No. of swing cylinder |
2pcs |
|||
|
Max. open & area of wood grapple |
700mm/0.08 m2 (STANDARD) |
|||
|
Max. load of hydraulic rotator |
1 ton(10KN) |
|||
|
Hydraulic rotator turning radius |
unlimited |
|||
|
Working pressure |
18-22Mpa |
|||
|
Control valve |
5/7 sets |
7/9 sets |
5/7 sets & 2/4 sets |
|
|
Power Unit |
6.5HP engine 6L hydraulic tank |
9HP engine 6L hydraulic tank |
9HP engine 6L hydraulic tank |
|
|
Hydraulic flow |
7.5L/min |
14.4L/min |
14.4L/min |
|
|
Weight |
190kg |
190kg |
190kg |
|
|
Timber Trailer |
||||
|
Max. load |
1500kg |
2000kg |
||
|
Total length |
3230mm |
3350mm |
||
|
Width with wheels |
1440mm |
1344 |
||
|
Height |
1600mm |
1600mm |
||
|
Height of front plate |
1100x700mm |
1100x700mm |
||
|
No. of "S" |
2sets |
3sets |
||
|
Length of loading area |
2120-3520mm |
2200mm |
||
|
Loading area volume |
1.6-3m3 |
1.6 m3 |
||
|
Min. ground clearance |
200mm |
200mm |
||
|
Standard wheel |
22x11-10 |
25x10-12 |
||
|
4WD drive |
x |
YES |
YES |
|
|
Telescopic trailer |
x |
x |
YES |
|
|
Swing angle |
x |
x |
±45° |
|
|
Remote control winch(Optional) |
_ |
_ |
_ |
|
|
Weight |
270kg |
390kg |
565kg |
|
|
40”HC |
24pcs |
24pcs |
||
-
