ATV-TTC34

市 场 价:¥0

优 惠 价:¥0

库  存:999

选择商品:

商品详细

Timber Crane

Model

ATV-TTC34

Max reach

3.4m

Lifting capacity(3.4m)

200kg

Lifting capacity(2m)

600kg

Turning radius of crane

360°

No. of swing cylinder

2pcs

Max. open & area of wood grapple

700mm/0.08 m2

Max. load of hydraulic rotator

1 ton(10KN)

Hydraulic rotator turning radius

unlimited

Working pressure

18-22Mpa

Control valve

5/7 sets

Power Unit

6.5HP engine

6L hydraulic tank

Weight

190kg

Timber Trailer

Max. load

1500kg

Total length

3230mm

Width with wheels

1440mm

Height

1600mm

Height of front plate

1100x700mm

No. of "S"

2 sets(optional 4 sets)

Length of loading area

2120-3520mm

Loading area volume

1.6--3m3

Min. ground clearance

200mm

Standard wheel

22x11-10

Weight

270kg

Packing quantity

12pcs in 20'' container

24pcs in 40'' container
